★12-micron high-performance thermal detector
★Sensitivity ≤ 20mK
★Digital zoom range: 1.0 to 4.0 times
★Integrated eye-safe laser rangefinder, with a ranging distance exceeding 700 meters
★Aluminum alloy shell
★ Equipped with a rechargeable 18500 battery and a built-in battery
★1024×768 resolution AMOLED display
★High frequency refresh: 50Hz
★Multiple aiming reticle patterns and colors to choose from
★Support impact-triggered video recording
★Support multiple distance zero calibration configurations
★Built-in 32GB storage, supports photo taking and video recording
★Built-in Wi-Fi module
★Supports mobile device app connection and supports Picture-in-Picture (PIP) function
|
Sensor Specifications |
|
|
Resolution, pixel |
256 × 192 |
|
Pixel Size, μm |
12 |
|
NETD, mK |
≤ 20 |
|
Frame Rate, Hz |
50 |
|
Optical Specifications |
|
|
Objective Lens, mm |
F25 /1.0 |
|
Field of View, ° |
7.5 × 5.7 |
|
Linear Field of View (H×V),m at 100m |
13.2 × 9.9 |
|
Visual Magnification, × |
3.5 ~ 14 |
|
Eye Relief, mm |
48 |
|
Diopter Adjustment, D |
-5 ~ +5 |
|
Exit pupil Diameter, mm |
10 |
|
Detection Range, m(Target size:1.7m×0.5m,P(n)=99%) |
1500 |
|
Display Specifications |
|
|
Type |
AMOLED |
|
Resolution, pixels |
1024 × 768 |
|
Size, inch |
0.39 |
|
Power Supply |
|
|
Battery Type |
Li-ion 18500 |
|
Max Operating Time (22ºC, h） |
8 |
|
Sevice Voltage, V |
3 ~ 4.2 |
|
External Power Supply, V |
5 (Type C) |
|
Physical Specifications |
|
|
Wi-Fi / APP |
Support |
|
(HuntIR) |
|
|
Photo / Video Recorder |
Support |
|
Recoil activated video |
Support |
|
MIC |
Support |
|
IP Rating |
IP67 |
|
Memory Capacity, GB |
32 |
|
Operating Temperature, ºC |
-20 ~ +50 |
|
Weight, g |
≤ 620 |
|
Dimension, mm |
216 × 76 × 46 |
|
Body Material |
Aluminium Alloy |
|
Connections and Compatibilities |
|
|
Max. recoil power on rifled |
6000 |
|
weapon (Eo), Joules |
|
|
Maximum impact |
1000g/0.4ms |
|
Mount |
Picatinny mount |
|
Laser Rangefinder |
|
|
Safety Class fo Laser |
Class1 |
|
Wavelength |
905nm |
|
Max.Measuring Range |
700m |
|
Measurement Accuracy |
±1m |
|
Min.Measuring Range |
10m |
|
Ballistic Correction |
YES |
