★The night vision can be outfitted with high-performance Gen 2 and Gen 3 image intensifier tubes in green or white phosphor.
★Battery Cover - Spring-Built-in Design
★The night vision can adding a 50 deg FOV for maximum visibility in the field.
★IR Indicator in FOV;Low Battery Indicator in FOV
★IP65 waterproof and dustproof level (upgradeable to IP67)
★Multilayer wideband lens coating
★Automatic brightness contro
★Bright light cut-off
★Built-in Infrared illuminator
★Helmet Flip Up On/Off
★Support detachable remote infrared light
★Support replacing high-magnification lenses (4X/6X/8X) for distant viewing.
★Supports both 1X CR123A lithium battery
★Support connecting to mobile phones/digital cameras/SLR cameras for photo and video recording.
Generation(IIT) | Gen2+ | Gen3 |
Resolution(lp/mm) | 60-64 | 64-72 |
Figure Of Merit（FOM） | 1400-1800 | 1600-2300 |
Sensitivity（µ A/lm） | 700-1000 | 850-1200 |
SNR | 23-28 | 28-32 |
Luminance Gain（cd/㎡/lx） | 8000-12000 | 10000-20000 |
Photocathode Type | S25 | GaAs |
Magnification（X） | 1 | |
FOV （deg,°） | 50 | |
Focal Length | 22.5 | |
Diopter Adjustment（deg,°） | +5/-5 | |
Parallelism of Optical Axis | <0.1 ° /0.5 | |
MTF | 120lp/mm | |
Optical Distortion | <0.5% Max / 3% Max | |
Relative Illumination | >75% | |
Range of Focus (m) | 0.25m to infinity | |
Dimensions（mm） | 101 X 67 X 49 | |
Weight（kg） | 0.27 | |
Power Supply (v) | 2.6-4.2 | |
Battery Type (v) | 1 X CR123A lithium battery | |
Battery Life（h） | 60 h – 100 h | |
Low Battery Indicator | Yes | |
Overall Power Consumption | <0. 1W | |
Bright Light Cut-off | Yes | |
Automatic Brightness Control | Yes | |
Multilayer Wideband Lens Coating | Yes | |
Flip-Up On-Off | Yes | |
Infrared Illuminator | Built-in | |
IR Indicator | Yes | |
IR Wavelength（nm） | 850 | |
Support detachable remote infrared light | Yes | |
Support replacing high-magnification lenses | Yes | |
Support connecting to mobile phones/digital cameras/SLR cameras | Yes | |
Battery Cover - Spring-Built-in Design | Yes | |
Rapid switching between left and right eyes | Yes | |
Assemble a binocular night vision device | Yes | |
Operating Temperature (°C ) | -51 to +49 | |
Storage Temperature(°C ) | -51 to +85 | |
Relative Humidity | 5%-98% | |
MTTF (h) | 10000 | |
Environmental Rating | IP65/ IP67 | |
Guarantee(yr) | 1 | |
