Shenzhen Daking Optoelectronics Co., Ltd.
★The night vision can be outfitted with high-performance Gen 2 and Gen 3 image intensifier tubes in green or white phosphor.
★IP65 waterproof and dustproof level (upgradeable to IP67)
★Multilayer wideband lens coating
★Automatic brightness control
★Adjustable angle of binoculars
★Helmet Flip Up On/Off
|
Generation(IIT) |
Gen2+ |
|
Resolution(lp/mm) |
60-64 |
|
Figure Of Merit（FOM） |
1400-1800 |
|
Sensitivity（µ A/lm） |
700-1000 |
|
SNR |
23-28 |
|
Luminance Gain（cd/㎡/lx） |
8000-12000 |
|
Photocathode Type |
S25 |
|
Magnification（X） |
1 |
|
FOV （deg,°） |
50-85 |
|
Focal Length |
22.5 |
|
Diopter Adjustment（deg,°） |
+2~-2 |
|
Parallelism of Optical Axis |
<0.1 ° /0.5 |
|
MTF |
120lp/mm |
|
Optical Distortion |
<0.5% Max / 3% Max |
|
Relative Illumination |
>75% |
|
Range of Focus (m) |
0.25m to infinity |
|
Dimensions（mm） |
136X101X68 |
|
Weight（kg） |
0.489 |
|
Switch Style |
Rotary switch |
|
Switch Position |
OFF / ON / IR |
|
Battery Type (v) |
CR123AX1/ Battery Pack（4 X CR123A） |
|
Battery Life（h） |
30 h – 80 h |
|
Low Battery Indicator |
Optional |
|
Overall Power Consumption |
<0. 2W |
|
Bright Light Cut-off |
Optional |
|
Automatic Brightness Control |
Optional |
|
Multilayer Wideband Lens Coating |
Yes |
|
Flip-Up On-Off |
Yes |
|
Infrared Illuminator |
Optional |
|
IR Indicator |
Optional |
|
Distance adjustment function |
Yes |
|
Eye Distance Range Locking Function |
Yes |
|
Eye Distance Adjustment Range（mm） |
60-79 |
|
Exit Pupil Distance （mm） |
36 |
|
Exit Pupil Diameter （mm） |
7 |
|
Operating Temperature (°C ) |
-40 to +55 |
|
Storage Temperature(°C ) |
-40 to +55 |
|
Relative Humidity |
5%-98% |
|
MTTF (h) |
10000 |
|
Environmental Rating |
IP65/ IP67 |
|
Guarantee(yr) |
1 |
